Tube Guide / Tube Pilot
It protects the tube end during installation of tubes into the shell of the heat exchanger and ensures accurate alignment of the tube while passing through the baffle plates.
Features of Tube Guide
- To ‘Pilot’ the tube through the tube sheets and baffle plates during tube insertion.
- High strength Nylon bristles holds Tube Guide Firmly in tube.
Technical Details
| Sizes Available | 1/2 " O.D. TO 2 1/2 " O.D. |
|---|---|
| Models Available | PTG-1 TO PTG-27 |
